Description
TD12B1 Comair Rotron 19032836A 176x176x107mm 12VDC 2.5A 30W 3250RPM 325CFM 553m³/h 65.2dB(A) Ball 0.67inH2O 167Pa 2 Wire Leads Axial DC fan
Specifications
| Model Number | TD12B1 |
|---|---|
| Air Flow | 325 CFM |
| Weight | 2250 g |
| Manufacturer | Comair Rotron |
| Series | Tarzan DC |
| Dimensions | 176x176x107 mm |
| Voltage Rating | 12 VDC |
| Fan Type | DC |
| Operating Voltage | 6 – 14VDC |
| Current Rating | 2.5 A |
| Power Rating | 30 W |
| Fan Speed | 3250 RPM |
| Air Flow (m3) | 553 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 19032836A |
| Noise Level | 65.2 dB(A) |
| Static Pressure | 0.67 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, cUL, UL |
| Lifetime @ Temp | 42000 Hrs @ 70°C |
| Propeller | Plastic, Black, UL94V-0 |
| Venturi | Plastic, Black, UL94V-0 |
| Termination | 2 Wire Leads |
| Category | Axial DC |
| Static Pressure Pa | 167 Pa |
