MGA4012YB-O20 Protechnic

$3.99

SKU: MGA4012YB-O20

Description

MGA4012YB-O20 Protechnic 12VDC 0.327m³/min 11.54CFM 97.12Pa 0.39inH2O 9000RPM 0.18A 2.16W 37.8dB(A) 40x40x20mm Ball Bearing 2 Wire Leads DC Axial Fan

Specifications

Model Number

MGA4012YB-O20

Actual Power

1.44 W

Fan Type

DC

Voltage Rating

12 VDC

Air Flow CMM

0.327 m³/min

Air Flow

11.54 CFM

Static Pressure Pa

97.12 Pa

Static Pressure mmAq

9.9 mmAq

Static Pressure

0.39 in H2O

Fan Speed

9000 RPM

Current Rating

0.18 A

Actual Current

0.12 A

Power Rating

2.16 W

Manufacturer

Protechnic Electric

Weight

32 g

Noise Level

37.8 dB(A)

Dimensions

40x40x20 mm

Bearing Type

Ball Bearing

Material Blade

Plastic

Material Frame

Plastic

Lifetime @ Temp

40000 Hrs @ 60°C

Operating Temperature

14 ~ 158°F (-10 ~ 70°C)

Storage Temperature

-40℃~70℃(5%~95% RH)

Approval Agency

CE, TUV, UL

Termination

2 Wire Leads

Category

Axial Fan

Features

Automatic restart,locked current protection

series

40*40*20mm seriesD
