Description
MDD48U1E Comair Rotron 19040404A 120x120x39mm 48VDC 0.8A 38.4W 6300RPM 210CFM 356.8m³/h 65.3dB(A) Ball 0.97inH2O 242Pa 3 Wire Leads Axial DC fan
Specifications
| Model Number | MDD48U1E |
|---|---|
| Air Flow | 210 CFM |
| Weight | 420 g |
| Manufacturer | Comair Rotron |
| Series | Muffin XL DC |
| Dimensions | 120x120x39 mm |
| Voltage Rating | 48 VDC |
| Fan Type | DC |
| Operating Voltage | 36-60VDC |
| Current Rating | 0.8 A |
| Power Rating | 38.4 W |
| Fan Speed | 6300 RPM |
| Air Flow (m3) | 356.8 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 19040404A |
| Noise Level | 65.3 dB(A) |
| Static Pressure | 0.97 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 90°C |
| Approval Agency | CE, cUL, UL |
| Lifetime @ Temp | 55000 Hrs @ 70°C |
| Propeller | Plastic, Black, UL 94V-0 |
| Venturi | Die-Cast Aluminum |
| Termination | 3 Wire Leads |
| Category | Axial DC |
| Static Pressure Pa | 242 Pa |
