Description
MC12K3 Comair Rotron 19039388A 120x120x32mm 12VDC 0.90A 10.8W 4100RPM 110CFM 187.0m³/h 50dB(A) Ball 0.45inH2O 112Pa 2 Wire Leads Axial DC fan
Specifications
| Model Number | MC12K3 |
|---|---|
| Air Flow | 110 CFM |
| Weight | 240 g |
| Manufacturer | Comair Rotron |
| Series | Muffin DC |
| Dimensions | 120x120x32 mm |
| Voltage Rating | 12 VDC |
| Fan Type | DC |
| Operating Voltage | 6 – 14VDC |
| Current Rating | 0.90 A |
| Power Rating | 10.8 W |
| Fan Speed | 4100 RPM |
| Air Flow (m3) | 187.0 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 19039388A |
| Noise Level | 50 dB(A) |
| Static Pressure | 0.45 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, cUL, UL |
| Lifetime @ Temp | 45000 Hrs @ 70°C |
| Propeller | Plastic, Black, UL 94V-0 |
| Venturi | Plastic, Black, UL 94V-0 |
| Termination | 2 Wire Leads |
| Category | Axial DC |
| Static Pressure Pa | 112 Pa |
