Description
GL24Z7 Comair Rotron 19039524A 120x120x39mm 24VDC 1.30A 31.2W 4100RPM 192CFM 326.2m³/h 59.4dB(A) Ball 0.79inH2O 197Pa 3 Wire Leads Axial DC fan
Specifications
| Model Number | GL24Z7 |
|---|---|
| Air Flow | 192 CFM |
| Weight | 420 g |
| Manufacturer | Comair Rotron |
| Series | Galaxy DC |
| Dimensions | 120x120x39 mm |
| Voltage Rating | 24 VDC |
| Fan Type | DC |
| Operating Voltage | 12 – 28VDC |
| Current Rating | 1.30 A |
| Power Rating | 31.2 W |
| Fan Speed | 4100 RPM |
| Air Flow (m3) | 326.2 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 19039524A |
| Noise Level | 59.4 dB(A) |
| Static Pressure | 0.79 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, cUL, UL |
| Lifetime @ Temp | 60000 Hrs @ 70°C |
| Propeller | Plastic, Black, UL 94V-0 |
| Venturi | Die-Cast Aluminum |
| Termination | 3 Wire Leads |
| Category | Axial DC |
| Static Pressure Pa | 197 Pa |
