Description
FFB0412UHN-CF00 Delta 40x40x28mm Ball 12VDC 27.053CFM(0.766m3/min) 2.111inchH2O 0.81A 58.5dB(A) 7.80W 18500RPM 3wireleads axial fan
Specifications
| Model | FFB0412UHN-CF00 |
|---|---|
| Manufacturer | Delta Electronics |
| Power Rating | 7.80 W |
| Approval Agency | CE, cURus, VDE |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Features | Locked Rotor Protection, Speed Sensor (Tach) |
| Series | FFB |
| Air Flow (m3) | 0.766 m3/min |
| Dimensions | 40x40x28 mm |
| Termination | 3 wire leads |
| Fan Speed | 18500 RPM |
| Fan Type | DC |
| Static Pressure | 2.111 inchH2O (53.631 mmH2O) |
| Noise Level | 58.5 dB(A) |
| Air Flow | 27.053 CFM |
| Voltage Rating | 12 VDC |
| Bearing Type | Ball Bearing |
| Weight | 0.104 lb (47.17 g) |
| Category | Axial |
| Current Rating | 0.81 A |
| Operating Voltage | 5.5 ~ 13.2 VDC |
| Material Frame | Plastic |
| Material Blade | Plastic |
| Lifetime @ Temp | 70000 Hrs @ 40⁰C |
| Subcategory | DC axial fan |
