DD402124K1R Comair Rotron

$38.89

SKU: DD402124K1R

Description

DD402124K1R Comair Rotron 19039824A 118x118x55mm 24VDC 1.33A 31.9W 5900RPM 116CFM 197.1m³/h 67dB(A) Ball 1.73inH2O 430Pa 3 Wire Leads Impeller fan

Specifications

Model Number

DD402124K1R

Air Flow

116 CFM

Weight

355 g

Manufacturer

Comair Rotron

Series

DD4021

Dimensions

118x118x55 mm

Voltage Rating

24 VDC

Fan Type

DC

Operating Voltage

12 – 32VDC

Current Rating

1.33 A

Power Rating

31.9 W

Fan Speed

5900 RPM

Air Flow (m3)

197.1 m³/h

Bearing Type

Ball Bearing

Part Number

19039824A

Noise Level

67 dB(A)

Static Pressure

1.73 in H2O

Operating Temperature

-40 ~ 158°F (-40 ~ 70°C)

Storage Temperature

-40°C to 85°C

Approval Agency

CE, cUL, UL

Lifetime @ Temp

52000 Hrs @ 40°C

Propeller

Plastic, Black, UL 94V-0

Venturi

Die Cast Aluminum

Termination

3 Wire Leads

Category

Impeller

Static Pressure Pa

430 Pa
