Description
CR4028-MD12BPL Comair Rotron 17002001A 40x40x28mm 12VDC 0.10A 1.20W 8000RPM 10.6CFM 18.4m³/h 45dB(A) Ball 0.32inH2O 79Pa 2 Wire Leads Axial DC fan
Specifications
| Model Number | CR4028-MD12BPL |
|---|---|
| Air Flow | 10.6 CFM |
| Weight | 50 g |
| Manufacturer | Comair Rotron |
| Series | CR4028 DC |
| Dimensions | 40x40x28 mm |
| Voltage Rating | 12 VDC |
| Fan Type | DC |
| Operating Voltage | 10.8-13.2VDC |
| Current Rating | 0.10 A |
| Power Rating | 1.20 W |
| Fan Speed | 8000 RPM |
| Air Flow (m3) | 18.4 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 17002001A |
| Noise Level | 45 dB(A) |
| Static Pressure | 0.32 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, UL |
| Lifetime @ Temp | 45000 Hrs @ 70°C |
| Propeller | Plastic, Black, UL 94V-0 |
| Venturi | Plastic, Black, UL 94V-0 |
| Termination | 2 Wire Leads |
| Category | Axial DC |
| Static Pressure Pa | 79 Pa |
