Description
CR2880DC48V Comair Rotron 17002086A 280x280x80mm 48VDC 2.60A 100W 3000RPM 1179.6CFM 2005.3m³/h 77dB(A) Ball 1.07inH2O 267Pa 2 Wire Leads Axial DC fan
Specifications
| Model Number | CR2880DC48V |
|---|---|
| Air Flow | 1179.6 CFM |
| Weight | 2050 g |
| Manufacturer | Comair Rotron |
| Series | CR2880 DC |
| Dimensions | 280x280x80 mm |
| Voltage Rating | 48 VDC |
| Fan Type | DC |
| Operating Voltage | 43.2-52.8VDC |
| Current Rating | 2.60 A |
| Power Rating | 100 W |
| Fan Speed | 3000 RPM |
| Air Flow (m3) | 2005.3 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 17002086A |
| Noise Level | 77 dB(A) |
| Static Pressure | 1.07 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, UL |
| Lifetime @ Temp | 50000 Hrs @ 40°C |
| Propeller | Die Cast magnesium alloy, ED coating and powder coating |
| Venturi | Die Cast magnesium alloy, ED coating and powder coating |
| Termination | 2 Wire Leads |
| Category | Axial DC |
| Static Pressure Pa | 267 Pa |
