Description
CD24B3 Comair Rotron 19031573A 254x89mm 24VDC 1.2A 28.8W 1650RPM 548CFM 931m³/h 49.1dB(A) Ball 0.41inH2O 102Pa 2 Wire Leads Axial DC fan
Specifications
| Model Number | CD24B3 |
|---|---|
| Air Flow | 548 CFM |
| Weight | 1540 g |
| Manufacturer | Comair Rotron |
| Series | Caravel DC |
| Dimensions | 254X89 mm |
| Voltage Rating | 24 VDC |
| Fan Type | DC |
| Operating Voltage | 12 – 28VDC |
| Current Rating | 1.2 A |
| Power Rating | 28.8 W |
| Fan Speed | 1650 RPM |
| Air Flow (m3) | 931 m³/h |
| Bearing Type | Ball Bearing |
| Part Number | 19031573A |
| Noise Level | 49.1 dB(A) |
| Static Pressure | 0.41 in H2O |
| Operating Temperature | -40 ~ 158°F (-40 ~ 70°C) |
| Storage Temperature | -40°C to 85°C |
| Approval Agency | CE, cUL, UL |
| Lifetime @ Temp | 65000 Hrs @ 40°C |
| Propeller | Plastic, Black, UL 94V-0 |
| Venturi | Die Cast Aluminum |
| Termination | 2 Wire Leads |
| Category | Axial DC |
| Static Pressure Pa | 102 Pa |
