AFB0412MA-AF00 Delta

$6.68

Datesheet:AFB0412MA-AF00.pdf
SKU: AFB0412MA-AF00

Description

AFB0412MA-AF00 Delta 40x40x10mm Ball 12VDC 5.652CFM(0.161m3/min) 0.104inH2O(2.65mmH2O) 21.5dB(A) 0.36W 5000RPM 3wireleads

Specifications

Part Number

AFB0412MA-AF00

Power Rating

0.36 W

Approval Agency

CE, CSA, UL, VDE

Operating Temperature

14 ~ 158°F (-10 ~ 70°C)

Features

Locked Rotor Protection, Speed Sensor (Tach)

Series

AFB

Air Flow (m3)

0.161 m3/min

Dimensions

40x40x10 mm

Termination

3 wire leads

Manufacturer

Delta Electronics

Fan Speed

5000 RPM

Fan Type

DC

Static Pressure

0.104 inH2O (2.65 mmH2O)

Noise Level

21.5 dB(A)

Air Flow

5.652 CFM

Voltage Rating

12 VDC

Bearing Type

Ball Bearing

Weight

0.031 lb (14.06 g)

Category

Axial

Current Rating

0.03 A

Operating Voltage

7 ~ 13.8 VDC

Material Frame

Plastic

Material Blade

Plastic

Lifetime @ Temp

70000 Hrs @ 40⁰C
