Description
AFB0405HA-A Delta 40x40x10mm Ball 5VDC 6.89CFM(0.195m3/min) 0.140inchH2O(3.60mmH2O) 27.0dB(A) 0.35W 6000RPM 2wireleads
Specifications
| Part Number | AFB0405HA-A |
|---|---|
| Power Rating | 0.35 W |
| Approval Agency | CE, CSA, UL, VDE |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
| Features | Locked Rotor Protection |
| Series | AFB |
| Air Flow (m3) | 0.195 m3/min |
| Dimensions | 40x40x10 mm |
| Termination | 2 wire leads |
| Manufacturer | Delta Electronics |
| Fan Speed | 6000 RPM |
| Fan Type | DC |
| Static Pressure | 0.140 inchH2O (3.60 mmH2O) |
| Noise Level | 27.0 dB(A) |
| Air Flow | 6.89 CFM |
| Voltage Rating | 5 VDC |
| Bearing Type | Ball Bearing |
| Weight | 0.031 lb (14.06 g) |
| Category | Axial |
| Current Rating | 0.07 A |
| Operating Voltage | 4.5 ~ 5.5 VDC |
| Material Frame | Plastic |
| Material Blade | Plastic |
| Lifetime @ Temp | 70000 Hrs @ 40⁰C |
