Description
9WFA0924P4H001 Sanyo Denki San Ace 92WF DC 24VDC 92x92x25.20mm 83CFM Ball 52dB(A) 6.72W 6100RPM 4 Wire Leads Locked Rotor Protection PWM Control Speed Sensor (Tach) Tubeaxial fan
Specifications
| Part Number | 9WFA0924P4H001 |
|---|---|
| Manufacturer | Sanyo Denki |
| Fan Type | DC |
| Series | San Ace 92WF |
| Voltage Rating | 24 VDC |
| Dimensions | 92x92x25.20 mm |
| Air Flow | 83 CFM |
| Air Flow (m3) | 2.32m³/min |
| Static Pressure | 0.690 in H2O (171.8 Pa) |
| Bearing Type | Ball Bearing |
| Features | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) |
| Noise Level | 52 dB(A) |
| Power Rating | 6.72 W |
| Fan Speed | 6100 RPM |
| Termination | 4 Wire Leads |
| Operating Temperature | -4 ~ 158°F (-20 ~ 70°C) |
| Approval Agency | cURus, TUV |
| Weight | 0.375 lb (170.1 g) |
| Subcategory | Tubeaxial |
