Description
109E5724C502 Sanyo Denki San Ace 172 DC 24VDC 172x150x51mm 350CFM Ball 66dB(A) 55.2W 4800RPM 2 Wire Leads Locked Rotor Protection Tubeaxial fan
Specifications
| Part Number | 109E5724C502 |
|---|---|
| Manufacturer | Sanyo Denki |
| Fan Type | DC |
| Series | San Ace 172 |
| Voltage Rating | 24 VDC |
| Dimensions | 172x150x51 mm |
| Air Flow | 350 CFM |
| Air Flow (m3) | 9.80m³/min |
| Static Pressure | 1.237 in H2O (308.0 Pa) |
| Bearing Type | Ball Bearing |
| Features | Locked Rotor Protection |
| Noise Level | 66 dB(A) |
| Power Rating | 55.2 W |
| Fan Speed | 4800 RPM |
| Termination | 2 Wire Leads |
| Operating Temperature | -4 ~ 158°F (-20 ~ 70°C) |
| Approval Agency | CSA, TUV, UL |
| Weight | 1.7 lbs (760.0 g) |
| Subcategory | Tubeaxial |
